Nimonic 80A Fasteners

Size In Ready Stock

• Stud Size = M4 To M100
• Screw Size = M1.2 To M48
• Nut Size = M2 To M80
• Washer Size = M2 To M24
• Bolts Size : M1.2 To M120

Nimonic 80A Bolts Head Style

• Flat
• Button
• Hex
• Truss
• Round

Neck Type of Nickel Alloy 80A Bolts

• Square
• Knurled
• Triangular
• Hex

Threads Types of UNS N07080 Bolts

• BSW
• UNF
• CBSF
• UN

Head Drive of DIN 2.4631

• Phillips
• Phillips/Slot
• Six-Lobe
• Slotted

Nimonic 80A Bolts & Nuts Ends Types

• Flat or Saw cut
• Chamfered
• Rounded
• Sheared

80A Nimonic Threaded Rod

• Condition : Cold Drawn or Threading
• Threads : Left and Right Hand, Both Side

Alloy 80A Stud Bolts

• End Types : Saw Cut, Flat and Rounded
• Threads : Double End, Fully or Fine Threaded

Nimonic N07080 Screws

• Threads Pitch : Fine and Coarse
• Head Shape : Round, Pan, Button

Nicrofer 7520 Washers

• Forms : A, D, C, G, B, E
• Thickness : 0.002" to ½"

Manufacturing Process

• CNC Machine
• Cold forging
• Hot forging

Advantages

• Fatigue Resistance
• Good Weldability
• Resistance to Oxidation

Testing Requirements

• Fatigue Testing
• NDT (Non-Destructive Testing)
• Tensile Test

Application

• Power Generation
• Aerospace
• Automotive

Packaging Types

• Custom
• Carton Box
• Wooden Cases

Raw Material

• German
• Janpanese
• European

• Aluminum (Al) = 1 - 1.8% (Maximum)
• Boron (B) = 0.008%
• Carbon (C) = 0.1% (Maximum)
• Chromium (Cr) = 18% - 21% (Maximum)

• Nickel (Ni) = Balanced
• Iron (Fe) = 3%
• Sulfur (S) = 0.015%
• Manganese (Mn) = 1%
